- Eaton Arrow Hart Blue Turn Locking Receptacle Outlet NEMA L6-20R 20A 250V 2P3W AHCL620R
Eaton Arrow Hart Blue Turn Locking Receptacle Outlet NEMA L6-20R 20A 250V 2P3W AHCL620R
Your Price: $12.99
QTY Available to Ship:
10
Fruit Ridge Tools is not an authorized distributor, reseller or representative of the products featured on this website. All product names, trademarks, brands and logos used on this site are the property of their respective owners. The depiction, description or sale of products featuring these names, trademarks, brands and logos is for identification purposes only and is not intended to indicate any affiliation with or authorization by any rights holder.
Product Description
Eaton Arrow Hart AHCL620R Hart-Lock color coded black and blue locking receptacle. Industrial Specification Grade, NEMA L6-20R, 2-pole, 3-wire, grounding, rated 20A 250V. Each is individually packaged; packaging may differ from photo. Features include:
- Rugged fiberglass reinforced, high temperature, nylon body reduces breakage
- One-piece brass alloy contacts provide excellent plug retention and continuity in the grounding and power circuits - provides superior performance and minimum heat rise
- Rugged heavy duty mounting strap - double riveted to body for added strength
- Compact body design allows for adequate wire room in wallbox
- Heavy interior walls provide additional support to insure contact retention
- Back and side wired terminal design allows for fast installation - large 10-32 power contact screws assure easy, efficient installation
- Serrated terminal plates bite wire to insure strong, reliable wiring connections
- Combination head screws (slot/Phillips) for fast, easy installation
MPN:
AHL620R
Cross Reference:
Not Available
Color:
Black
Amperage:
20A
Condition:
New
UPC:
040893676999
Weight:
0.30 LBS
Most orders ship same day if received by 2:00 pm EST Mon-Fri and 12:00 pm EST Sat. Some larger orders or items that require special handling may be shipped next business day.
